Image Stitching with OpenCV and Python

In this tutorial, you will learn how to perform image stitching using Python, OpenCV, and the cv2.createStitcher  and cv2.Stitcher_create  functions. Using today’s code you’ll be able to stitch multiple images together, creating a panorama of stitched images.

Just under two years ago I published two guides on image stitching and panorama construction:

  1. Fundamentals of image stitching

  2. Real-time panorama and image stitching

Both of these tutorials covered the fundamentals of the typical image stitching algorithm, which, at a bare minimum, require four key steps:

  1. Detecting keypoints (DoG, Harris, etc.) and extracting local invariant descriptors (SIFT, SURF, etc.) from two input images

  2. Matching the descriptors between the images

  3. Using the RANSAC algorithm to estimate a homography matrix using our matched feature vectors

  4. Applying a warping transformation using the homography matrix obtained from Step #3

However, the biggest problem with my original implementations is that they were not capable of handling more than two input images.

In today’s tutorial, we’ll be revisiting image stitching with OpenCV, including how to stitch more than two images together into a panoramic image.

To learn how to stitch images with OpenCV and Python, just keep reading!

Image Stitching with OpenCV and Python

In the first part of today’s tutorial, we’ll briefly review OpenCV’s image stitching algorithm that is baked into the OpenCV library itself via cv2.createStitcher  and cv2.Stitcher_create  functions.

From there we’ll review our project structure and implement a Python script that can be used for image stitching.

We’ll review the results of this first script, note its limitations, and then implement a second Python script that can be used for more aesthetically pleasing image stitching results.

Finally, we’ll review the results of our second script and again note any limitations or drawbacks.

OpenCV’s image stitching algorithm

Figure 1: The stitching module pipeline implemented in the Stitcher class (source).

The algorithm we’ll be using here today is similar to the method proposed by Brown and Lowe in their 2017 paper, Automatic Panoramic Image Stitching with Invariant Features.

Unlike previous image stitching algorithms which are sensitive to the ordering of input images, the Brown and Lowe method is more robust, making it insensitive to:

  • Ordering of images

  • Orientation of images

  • Illumination changes

  • Noisy images that are not actually part of the panorama

Furthermore, their image stitching method is capable of producing more aesthetically pleasing output panorama images through the use of gain compensation and image blending.

A complete, detailed review of the algorithm is outside the scope of this post, so if you’re interested in learning more, please refer to the original publication.

Project structure

Let’s see how this project is organized with the tree  command:

  $ tree –dirsfirst.├── images│   └── scottsdale│       ├── IMG_1786-2.jpg│       ├── IMG_1787-2.jpg│       └── IMG_1788-2.jpg├── image_stitching.py├── image_stitching_simple.py└── output.png 2 directories, 6 files

.

│   └── scottsdale

│       ├── IMG_1787-2.jpg

├── image_stitching.py

└── output.png

2 directories, 6 files

The input images go in the images/  folder. I opted to make a subfolder for my scottsdale/  set of images in case I wanted to add additional subfolders here later.

Today we’ll be reviewing two Python scripts:

image_stitching_simple.py : Our simple version of image stitching can be completed in less than 50 lines of Python code!

image_stitching.py : This script includes my hack to extract an ROI of the stitched image for an aesthetically pleasing result.

The last file, output.png , is the name of the resulting stitched image. Using command line arguments, you can easily change the filename + path of the output image.

The cv2.createStitcher and cv2.Stitcher_create functions

Figure 2: The constructor signature for creating a Stitcher class object with OpenCV.

OpenCV has already implemented a method similar to Brown and Lowe’s paper via the cv2.createStitcher  (OpenCV 3.x) and cv2.Stitcher_create  (OpenCV 4) functions.

Assuming you have OpenCV properly configured and installed you’ll be able to investigate the function signature of cv2.createStitcher  for OpenCV 3.x:

  createStitcher(…)    createStitcher([, try_use_gpu]) -> retval

    createStitcher([, try_use_gpu]) -> retval

Notice how this function has only a single parameter, try_gpu  which can be used to improve your the throughout of your image stitching pipeline. OpenCV’s GPU support is limited and I’ve never been able to get this parameter to work so I recommend always leaving it as False .

The cv2.Stitcher_create  function for OpenCV 4 has a similar signature:

  Stitcher_create(…)    Stitcher_create([, mode]) -> retval    .   @brief Creates a Stitcher configured in one of the stitching    . modes.    .       .   @param mode Scenario for stitcher operation. This is usually    . determined by source of images to stitch and their transformation.    . Default parameters will be chosen for operation in given scenario.    .   @return Stitcher class instance.

    Stitcher_create([, mode]) -> retval

    . modes.

    .   @param mode Scenario for stitcher operation. This is usually

    . Default parameters will be chosen for operation in given scenario.

To perform the actual image stitching we’ll need to call the .stitch  method:

  OpenCV 3.x:stitch(…) method of cv2.Stitcher instance    stitch(images[, pano]) -> retval, pano OpenCV 4.x:stitch(…) method of cv2.Stitcher instance    stitch(images, masks[, pano]) -> retval, pano    .   @brief These functions try to stitch the given images.    .       .   @param images Input images.    .   @param masks Masks for each input image specifying where to    . look for keypoints (optional).    .   @param pano Final pano.    .   @return Status code.

stitch(…) method of cv2.Stitcher instance



stitch(…) method of cv2.Stitcher instance

    .   @brief These functions try to stitch the given images.

    .   @param images Input images.

    . look for keypoints (optional).

    .   @return Status code.

This method accepts a list of input images , and then attempts to stitch them into a panorama, returning the output panorama image to the calling function.

The status  variable indicates whether or not the image stitching was a success and can be one of four variables:

OK = 0 : The image stitching was a success.

ERR_NEED_MORE_IMGS = 1 : In the event you receive this status code, you will need more input images to construct your panorama. Typically this error occurs if there are not enough keypoints detected in your input images.

ERR_HOMOGRAPHY_EST_FAIL = 2 : This error occurs when the RANSAC homography estimation fails. Again, you may need more images or your images don’t have enough distinguishing, unique texture/objects for keypoints to be accurately matched.

ERR_CAMERA_PARAMS_ADJUST_FAIL = 3 : I have never encountered this error before so I don’t have much knowledge about it, but the gist is that it is related to failing to properly estimate camera intrinsics/extrinsics from the input images. If you encounter this error you may need to refer to the OpenCV documentation or even dive into the OpenCV C++ code.

Now that we’ve reviewed the cv2.createStitcher , cv2.Stitcher_create , and .stitch  methods, let’s move on to actually implementing image stitching with OpenCV and Python.

Implementing image stitching with Python

Let’s go ahead and get started implementing our image stitching algorithm!

Open up the image_stitching_simple.py  file and insert the following code:

  # import the necessary packagesfrom imutils import pathsimport numpy as npimport argparseimport imutilsimport cv2 # construct the argument parser and parse the argumentsap = argparse.ArgumentParser()ap.add_argument(“-i”, “–images”, type=str, required=True, help=”path to input directory of images to stitch”)ap.add_argument(“-o”, “–output”, type=str, required=True, help=”path to the output image”)args = vars(ap.parse_args())

from imutils import paths

import argparse

import cv2

construct the argument parser and parse the arguments

ap.add_argument(“-i”, “–images”, type=str, required=True,

ap.add_argument(“-o”, “–output”, type=str, required=True,

args = vars(ap.parse_args())

Our required packages are imported on Lines 2-6. Notably, we’ll be using OpenCV and imutils. If you haven’t already, go ahead and install them:

  • To install OpenCV, just follow one of my OpenCV installation guides.

The imutils package can be installed/updated with pip: pip install –upgrade imutils . Be sure to upgrade it as new features are often added.

From there we’ll parse two command line arguments on Lines 9-14:

–images : The path to the directory of input images to stitch.

–output : The path to the output image where the result will be saved.

If you aren’t familiar with the concepts of argparse  and command line arguments then read this blog post.

Let’s load our input images:

  # grab the paths to the input images and initialize our images listprint(“[INFO] loading images…“)imagePaths = sorted(list(paths.list_images(args[“images”])))images = [] # loop over the image paths, load each one, and add them to our# images to stitch listfor imagePath in imagePaths: image = cv2.imread(imagePath) images.append(image)

print(“[INFO] loading images…”)

images = []

loop over the image paths, load each one, and add them to our

for imagePath in imagePaths:

images.append(image)

Here we grab our imagePaths  (Line 18).

Then for each imagePath , we’ll load the image  and add it to the images  list (Lines 19-25).

Now that the images  are in memory, let’s go ahead and stitch them together into a panorama using OpenCV’s built-in capability:

  # initialize OpenCV’s image stitcher object and then perform the image# stitchingprint(“[INFO] stitching images…“)stitcher = cv2.createStitcher() if imutils.is_cv3() else cv2.Stitcher_create()(status, stitched) = stitcher.stitch(images)

stitching

stitcher = cv2.createStitcher() if imutils.is_cv3() else cv2.Stitcher_create()

The stitcher  object is created on Line 30. Notice that depending on whether you’re using OpenCV 3 or 4, a different constructor is called.

Subsequently, we can pass our images  to the .stitch  method (Line 31). The call to .stitch  returns both a status  and our stitched  image (assuming the stitching was successful).

Finally, we’ll both (1) write the stitched image to disk and (2) display it on the screen:

3334353637383940414243444546 # if the status is ‘0’, then OpenCV successfully performed image# stitchingif status == 0: # write the output stitched image to disk cv2.imwrite(args[“output”], stitched)  # display the output stitched image to our screen cv2.imshow(“Stitched”, stitched) cv2.waitKey(0) # otherwise the stitching failed, likely due to not enough keypoints)# being detectedelse: print(“[INFO] image stitching failed ({})”.format(status))

34

36

38

40

42

44

46

stitching

# write the output stitched image to disk



cv2.imshow(“Stitched”, stitched)



being detected

print(“[INFO] image stitching failed ({})”.format(status))

Assuming our status  flag indicates success (Line 35), we write the stitched  image to disk (Line 37) and display it until a key is pressed (Lines 40 and 41).

Otherwise, we’ll simply print a failure message (Lines 45 and 46).

Basic image stitching results

To give our image stitching script a try, make sure you use the “Downloads” section of the tutorial to download the source code and example images.

Inside the images/scottsdale/  directory you will find three photos that I took when visiting Frank Lloyd Wright’s famous Taliesin West house in Scottsdale, AZ:

Figure 3: Three photos to test OpenCV image stitching with. These images were taken by me in Scottsdale, AZ at Frank Lloyd Wright’s famous Taliesin West house.

Our goal is to stitch these three images into a single panoramic image. To perform the stitching, open up a terminal, navigate to where you downloaded the code + images, and execute the following command:

  $ python image_stitching_simple.py –images images/scottsdale –output output.png[INFO] loading images…[INFO] stitching images…

[INFO] loading images…

Figure 4: Image stitching performed with OpenCV. This image has undergone stitching but has yet to be cropped.

Notice how we have successfully performed image stitching!

But what about those black regions surrounding the panorama? What are those?

Those regions are from performing the perspective warps required to construct the panorama.

There is a way to get rid of them…but we’ll need to implement some additional logic in the next section.

A better image stitcher with OpenCV and Python

Figure 5: In this section, we’ll learn how to improve image stitching with OpenCV by cropping out the region of the panorama inside the red-dash border shown in the figure.

Our first image stitching script was a good start but those black regions surrounding the panorama itself are not something we would call “aesthetically pleasing”.

And more to the point, you wouldn’t see such an output image from popular image stitching applications built into iOS, Android, etc.

Therefore, we’re going to hack our script a bit and include some additional logic to create more aesthetically pleasing panoramas.

I’m going to again reiterate that this method is a hack.

We’ll be reviewing basic image processing operations including threshold, contour extraction, morphological operations, etc. in order to obtain our desired result.

To my knowledge, OpenCV’s Python bindings do not provide us with the required information to manually extract the maximum inner rectangular region of the panorama. If OpenCV does, please let me know in the comments as I would love to know.

Let’s go ahead and get started — open up the image_stitching.py  script and insert the following code:

123456789101112131415161718192021222324252627282930313233 # import the necessary packagesfrom imutils import pathsimport numpy as npimport argparseimport imutilsimport cv2 # construct the argument parser and parse the argumentsap = argparse.ArgumentParser()ap.add_argument(“-i”, “–images”, type=str, required=True, help=”path to input directory of images to stitch”)ap.add_argument(“-o”, “–output”, type=str, required=True, help=”path to the output image”)ap.add_argument(“-c”, “–crop”, type=int, default=0, help=”whether to crop out largest rectangular region”)args = vars(ap.parse_args()) # grab the paths to the input images and initialize our images listprint(“[INFO] loading images…“)imagePaths = sorted(list(paths.list_images(args[“images”])))images = [] # loop over the image paths, load each one, and add them to our# images to stich listfor imagePath in imagePaths: image = cv2.imread(imagePath) images.append(image) # initialize OpenCV’s image sticher object and then perform the image# stitchingprint(“[INFO] stitching images…“)stitcher = cv2.createStitcher() if imutils.is_cv3() else cv2.Stitcher_create()(status, stitched) = stitcher.stitch(images)

2

4

6

8

10

12

14

16

18

20

22

24

26

28

30

32

from imutils import paths

import argparse

import cv2

construct the argument parser and parse the arguments

ap.add_argument(“-i”, “–images”, type=str, required=True,

ap.add_argument(“-o”, “–output”, type=str, required=True,

ap.add_argument(“-c”, “–crop”, type=int, default=0,

args = vars(ap.parse_args())

grab the paths to the input images and initialize our images list

imagePaths = sorted(list(paths.list_images(args[“images”])))



images to stich list

image = cv2.imread(imagePath)



stitching

stitcher = cv2.createStitcher() if imutils.is_cv3() else cv2.Stitcher_create()

All of this code is identical to our previous script with one exception.

The –crop  command line argument has been added. When a 1  is provided for this argument in the terminal, we’ll go ahead and perform our cropping hack.

The next step is where we start implementing additional functionality:

35363738394041424344454647484950 # if the status is ‘0’, then OpenCV successfully performed image# stitchingif status == 0: # check to see if we supposed to crop out the largest rectangular # region from the stitched image if args[“crop”] > 0: # create a 10 pixel border surrounding the stitched image print(“[INFO] cropping…”) stitched = cv2.copyMakeBorder(stitched, 10, 10, 10, 10, cv2.BORDER_CONSTANT, (0, 0, 0))  # convert the stitched image to grayscale and threshold it # such that all pixels greater than zero are set to 255 # (foreground) while all others remain 0 (background) gray = cv2.cvtColor(stitched, cv2.COLOR_BGR2GRAY) thresh = cv2.threshold(gray, 0, 255, cv2.THRESH_BINARY)[1]

36

38

40

42

44

46

48

50

stitching

# check to see if we supposed to crop out the largest rectangular

if args[“crop”] > 0:

print(“[INFO] cropping…”)

cv2.BORDER_CONSTANT, (0, 0, 0))

# convert the stitched image to grayscale and threshold it

# (foreground) while all others remain 0 (background)

thresh = cv2.threshold(gray, 0, 255, cv2.THRESH_BINARY)[1]

Notice how I’ve made a new block for when the –crop  flag is set on Line 40. Let’s begin going through this block:

First, we’ll add a 10  pixel border to all sides of our stitched  image (Lines 43 and 44), ensuring we’ll be able to find contours of the complete panorama outline later in this section. Then we’re going to create a gray  version of our stitched  image (Line 49). And from there we threshold the gray  image (Line 50).

Here is the result ( thresh ) of those three steps:

Figure 6: After thresholding, we’re presented with this threshold mask highlighting where the OpenCV stitched + warped image resides.

We now have a binary image of our panorama where white pixels (255) are the foreground and black pixels (0) are the background.

Given our thresholded image we can apply contour extraction, compute the bounding box of the largest contour (i.e., the outline of the panorama itself), and draw the bounding box:

52535455565758596061626364 # find all external contours in the threshold image then find # the largest contour which will be the contour/outline of # the stitched image cnts = cv2.findContours(thresh.copy(), cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE) cnts = imutils.grab_contours(cnts) c = max(cnts, key=cv2.contourArea)  # allocate memory for the mask which will contain the # rectangular bounding box of the stitched image region mask = np.zeros(thresh.shape, dtype=”uint8”) (x, y, w, h) = cv2.boundingRect(c) cv2.rectangle(mask, (x, y), (x + w, y + h), 255, -1)

53

55

57

59

61

63

# the largest contour which will be the contour/outline of

cnts = cv2.findContours(thresh.copy(), cv2.RETR_EXTERNAL,

cnts = imutils.grab_contours(cnts)



# rectangular bounding box of the stitched image region

(x, y, w, h) = cv2.boundingRect(c)

Contours are extracted and parsed on Lines 55-57Line 58 then grabs the contour with the largest area (i.e., the outline of the stitched image itself).

Note: The imutils.grab_contours  function is new in imutils==0.5.2  to accommodate OpenCV 2.4, OpenCV 3, and OpenCV 4 and their different return signatures for cv2.findContours .

Line 62 allocates memory for our new rectangular mask. Line 63 then calculates the bounding box of our largest contour. Using the bounding rectangle information, on Line 64, we draw a solid white rectangle on the mask.

The output of the above code block would look like the following:

Figure 7: The smallest rectangular region that the entire OpenCV panorama can fit in.

This bounding box is the smallest rectangular region that the entire panorama can fit in.

Now, here comes one of the biggest hacks I’ve ever put together for a blog post:

666768697071727374757677787980 # create two copies of the mask: one to serve as our actual # minimum rectangular region and another to serve as a counter # for how many pixels need to be removed to form the minimum # rectangular region minRect = mask.copy() sub = mask.copy()  # keep looping until there are no non-zero pixels left in the # subtracted image while cv2.countNonZero(sub) > 0: # erode the minimum rectangular mask and then subtract # the thresholded image from the minimum rectangular mask # so we can count if there are any non-zero pixels left minRect = cv2.erode(minRect, None) sub = cv2.subtract(minRect, thresh)

67

69

71

73

75

77

79

# minimum rectangular region and another to serve as a counter

# rectangular region

sub = mask.copy()

# keep looping until there are no non-zero pixels left in the

while cv2.countNonZero(sub) > 0:

# the thresholded image from the minimum rectangular mask

minRect = cv2.erode(minRect, None)

On Lines 70 and 71 we create two copies of our mask  image:

The first mask, minMask , will be slowly reduced in size until it can fit inside the inner part of the panorama (see Figure 5 at the top of this section). The second mask, sub , will be used to determine if we need to keep reducing the size of minMask .

Line 75 starts a while  loop that will continue looping until there are no more foreground pixels in sub .

Line 79 performs an erosion morphological operation to reduce the size of minRect .

Line 80 then subtracts thresh  from minRect  — once there are no more foreground pixels in minRect  then we can break from the loop.

I have included an animation of the hack below:

Figure 8: An animation of the hack I came up with to extract the minRect region of the OpenCV panorama image, making for an aesthetically pleasing stitched image

On the top, we have our sub  image and on the bottom we have the minRect  image.

Notice how the size of minRect  is progressively reduced until there are no more foreground pixels left in sub  — at this point we know we have found the smallest rectangular mask that can fit into the largest rectangular region of the panorama.

Given the minimum inner rectangle we can again find contours and compute the bounding box, but this time we’ll simply extract the ROI from the stitched  image:

  # find contours in the minimum rectangular mask and then # extract the bounding box (x, y)-coordinates cnts = cv2.findContours(minRect.copy(), cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE) cnts = imutils.grab_contours(cnts) c = max(cnts, key=cv2.contourArea) (x, y, w, h) = cv2.boundingRect(c)  # use the bounding box coordinates to extract the our final # stitched image stitched = stitched[y:y + h, x:x + w]

# extract the bounding box (x, y)-coordinates

cv2.CHAIN_APPROX_SIMPLE)

c = max(cnts, key=cv2.contourArea)



# stitched image

Here we have:

Found contours in minRect  (Lines 84 and 85). Handled parsing contours for multiple OpenCV versions (Line 86). You’ll need imutils>=0.5.2  to use this function.

  • Grabbed the largest contour (Line 87).

  • Computed the bounding box of the largest contour (Line 88).

Extracted the ROI from our stitched using the bounding box information (Line 92).

The final stitched  image can be displayed to our screen and then saved to disk:

949596979899100101102103104 # write the output stitched image to disk cv2.imwrite(args[“output”], stitched)  # display the output stitched image to our screen cv2.imshow(“Stitched”, stitched) cv2.waitKey(0) # otherwise the stitching failed, likely due to not enough keypoints)# being detectedelse: print(“[INFO] image stitching failed ({})”.format(status))

95

97

99

101

103

cv2.imwrite(args[“output”], stitched)

# display the output stitched image to our screen

cv2.waitKey(0)

otherwise the stitching failed, likely due to not enough keypoints)

else:

Lines 95-99 handle saving and displaying the image regardless of whether or not our cropping hack is performed.

Just as before, if the status  flag didn’t come back as a success, we’ll print an error message (Lines 103 and 104).

Let’s go ahead and check out the results of our improved image stitching + OpenCV pipeline.

Improved image stitching results

Again, make sure you have used the “Downloads” section of today’s tutorial to download the source code and example images.

From there, open up a terminal and execute the following command:

  $ python image_stitching.py –images images/scottsdale –output output.png \ –crop 1[INFO] loading images…[INFO] stitching images…[INFO] cropping…

–crop 1

[INFO] stitching images…

Figure 8: The result of our multiple image stitching with OpenCV and Python.

Notice how this time we have removed the black regions from the output stitched images (caused by the warping transformations) by applying our hack detailed in the section above.

Limitations and drawbacks

In a previous tutorial, I demonstrated how you could build a real-time panorama and image stitching algorithm — this tutorial hinged on the fact that we were manually performing keypoint detection, feature extraction, and keypoint matching, giving us access to the homography matrix used to warp our two input images into a panorama.

And while OpenCV’s built-in cv2.createStitcher  and cv2.Stitcher_create  functions are certainly capable of constructing accurate, aesthetically pleasing panoramas, one of the primary drawbacks of the method is that it abstracts away any access to the homography matrices.

One of the assumptions of real-time panorama construction is that the scene itself is not changing much in terms of content.

Once we compute the initial homography estimation we should only have to occasionally recompute the matrix.

Not having to perform a full-blown keypoint matching and RANSAC estimation gives us a tremendous boost of speed when building our panorama, so without access to the raw homography matrices, it would be challenging to take OpenCV’s built-in image stitching algorithm and convert it to real-time.

Running into errors when performing image stitching using OpenCV?

It is possible that you may run into errors when trying to use either the cv2.createStitcher  function or cv2.Stitcher_create  functions.

The two “easy to resolve” errors I see people encounter is forgetting what version of OpenCV they are using.

For example, if you are using OpenCV 4 but try to call cv2.createSticher  you will encounter the following error message:

  »> cv2.createStitcherTraceback (most recent call last):  File “", line 1, in AttributeError: module 'cv2' has no attribute 'createStitcher'

Traceback (most recent call last):

AttributeError: module ‘cv2’ has no attribute ‘createStitcher’

You should instead be using the cv2.Stitcher_create  function.

Similarly, if you are using OpenCV 3 and you try to call cv2.Sticher_create  you will receive this error:

  »> cv2.Stitcher_createTraceback (most recent call last):  File “", line 1, in AttributeError: module 'cv2' has no attribute 'Stitcher_create'

Traceback (most recent call last):

AttributeError: module ‘cv2’ has no attribute ‘Stitcher_create’

Instead, use the cv2.createSticher  function.

If you are unsure which OpenCV version you are using you can check using cv2.version :

  »> cv2.version‘4.0.0’

‘4.0.0’

Here you can see that I am using OpenCV 4.0.0.

You can perform the same check on your system.

The final error that you can encounter, and arguably the most common, is related to OpenCV (1) not having contrib support and (2) being compiled without the OPENCV_ENABLE_NONFREE=ON  option enabled.

To resolve this error you must have the opencv_contrib  modules installed along with the OPENCV_ENABLE_NONFREE  option set to ON .

If you are encountering an error related to OpenCV’s non-free and contrib modules, make sure you refer to my OpenCV install guides to ensure you have the full install of OpenCV.

Note: Please note that I cannot help debug your own OpenCV install if you did not follow one of my install guides so please make sure you’re using my OpenCV install guides when configuring your system.

Summary

In today’s tutorial you learned how to perform multiple image stitching using OpenCV and Python.

Using both OpenCV and Python we were able to stitch multiple images together and create panoramic images.

Our output panoramic images were not only accurate in their stitching placement but also aesthetically pleasing as well.

However, one of the biggest drawbacks of using OpenCV’s built-in image stitching class is that it abstracts away much of the internal computation, including the resulting homography matrices themselves.

If you are trying to perform real-time image stitching, as we did in a previous post, you may find it beneficial to cache the homography matrix and only occasionally perform keypoint detection, feature extraction, and feature matching.

Skipping these steps and using the cached matrix to perform perspective warping can reduce the computational burden of your pipeline and ultimately speed-up the real-time image stitching algorithm, but unfortunately, OpenCV’s cv2.createStitcher  Python bindings do not provide us with access to the raw matrices.

If you are interested in learning more about real-time panorama construction, please refer to my previous post.

I hope you enjoyed today’s tutorial on image stitching!

To download the source code to today’s post, and be notified tutorials are published here on PyImageSearch, just enter your email address in the form below!

Downloads:
